Horsch 00311357 BISON Tungsten ULD Share Point
This ULD (Ultra Low Disturbance) share point features a tungsten carbide reinforced working surface, which significantly increases wear resistance and maintains a sharp working profile even in highly abrasive soils. The design allows deep soil penetration while minimizing surface disturbance, improving soil structure and reducing fuel consumption during tillage operations.
Product Overview
Horsch 00311357 BISON Tungsten ULD Share Point
OEM Replacement Horsch 00311357 Tungsten Carbide ULD Share Point for Deep Cultivation Systems
The Horsch 00311357 BISON Tungsten ULD Share Point is a high-performance wear part designed for heavy-duty soil cultivation, deep loosening, and stubble cultivation systems. It is engineered for use on Horsch cultivators such as Terrano, Tiger, and Focus series, where deep penetration and long service life are required under extreme abrasive soil conditions.
This ULD (Ultra Low Disturbance) share point features a tungsten carbide reinforced working surface, which significantly increases wear resistance and maintains a sharp working profile even in highly abrasive soils. The design allows deep soil penetration while minimizing surface disturbance, improving soil structure and reducing fuel consumption during tillage operations.
As a critical ground-engaging tool, this share point directly impacts working depth stability, traction efficiency, and overall cultivation performance.
Dawopu supplies OEM-quality and heavy-duty aftermarket wear parts for Horsch cultivation systems worldwide.
Product Features
- OEM Part Number: 00311357
- Product Name: BISON Tungsten ULD Share Point
- Tungsten carbide reinforced wear zones
- Ultra Low Disturbance (ULD) working geometry
- High penetration efficiency in compact soils
- Excellent abrasion resistance and long service life
- Maintains sharp working profile under heavy load
- Reduced soil resistance and fuel consumption
- Precision fit for Horsch tine systems
- Heavy-duty field performance
- OEM-quality replacement
Compatible Horsch Equipment
The Horsch 00311357 BISON Tungsten ULD Share Point is commonly used on:
Cultivator Series
- Horsch Terrano FX / GX / FM Series
- Horsch Tiger AS / MT Series
- Horsch Focus TD / Focus Series
- Horsch Deep Tillage Systems
- Horsch Stubble Cultivators
Application Systems
- Deep loosening cultivators
- Stubble cultivation systems
- Minimum tillage machines
- Conservation agriculture equipment
Always confirm compatibility using OEM part number and machine configuration.
Technical Specifications
Technical Specifications
| Item | Specification |
|---|---|
| Part Number | 00311357 |
| Product Name | ULD Share Point (BISON Tungsten) |
| Application | Deep Cultivation / Stubble Cultivator |
| Material | Boron Steel + Tungsten Carbide Inserts |
| Manufacturing Process | Forging + Hardfacing + Carbide Welding |
| Working Width | ~25–35 mm |
| Length | ~370–420 mm |
| Weight | ~4.2–4.4 kg |
| Surface Treatment | Tungsten Carbide Reinforced Wear Edge |
| Condition | New |
| OEM Replacement | Yes |
Material & Technology
The Horsch 00311357 share point uses advanced wear protection technology to extend working life in extreme soil conditions.
Material Structure
- High-strength boron steel body
- Tungsten carbide wear plates
- Hardfaced reinforcement zones
- Heat-treated core structure
Key Advantages
- Extremely high abrasion resistance
- Long service life in sandy and rocky soils
- Maintains sharp penetration edge
- Reduced deformation under impact load
- Stable performance in deep tillage
The tungsten reinforcement ensures consistent performance even in the most demanding agricultural environments.
