TOWING EYE
CAT IV 00346487
CAT V 00346488
BOLTS x12. 00360858
FAN
COMPLETE FAN ASSEMBLY. 60015316 FAN W/O MOTOR. 23466503
FAN COUPLING. 00380126
FAN MOTOR. 00380127 FAN MOTOR SEAL KIT. 00111430 HYDRAULIC PRESSURE GAUGE. 00110144 FAN BASKET. 23473900
SEED TUBE
UPRIGHT FEED PIPE 24648300 SHORT FEED PIPE (1300mm). 00180107
LONG FEED PIPE (6000mm). 00180004 FEED PIPE CLAMP. 00190347 DISTRIBUTOR CONNECTORS. 23011001
DISTRIBUTOR BLANK PLUG. 23011002
HOSE ADAPTOR ELBOW. 00190189
HOSE ADAPTOR STRAIGHT. 00190203
30mm SEED HOSE (90mtr roll) 00180123
30mm SEED HOSE (50mtr roll) 00180124
SEED TUBE CLAMPS. Grey 00210238
Black 00210237
SEED FLOW SENSOR. 0034612
METERING UNIT
GEARBOX MOTOR. 00340616 ELECTRICAL CONNECTOR KIT. 00340636 KEY. 00280414 FLANGE HOUSING. 01503228
DRIVE COUPLING. 33336100 BEARING. 00240001
SPINDLE. 01501904
ROTOR SHAFT. 01501905
BEARING FLANGE 01503221 SEAL. 00240002
GASKET. 01507801 M8 BUTTERFLY BOLT. 01503224
DEPTH WHEEL (PER SIDE)
DEPTH ADJUSTER. 34436700 YOKE. 00130997
BUSHES. 2x 00230083
00230004
00230005
PIN - ADJUSTER x2. 33783305
PIN - SUPPORT ARM. 34219611
HUB ASSEMBLY. 00310031
DEPTH STOPPERS KIT. 00170125
GAUGE WHEEL
DEPTH WHEEL - SOLID. 00311507
DEPTH WHEEL - SPOKED. 00311389 TYRE. 00311201 NARROW GAUGE WHEEL. 95161068 BEARING. 00310926
BOLT. 00360252
WASHER. 00170043
CRANK ARM. L/H 23224021
R/H 23225021 ADJUSTING SHIM. 00230103
COULTER DISC DISC. 00311214UB
DISC BOLTS. 00360949
COULTER ARM. L/H 23224070
R/H 23225070 COULTER ARM CLAMP. 23224009 CLAMP BOLTS. 00360461
CLAMP NUTS. 00350084
RUBBER STRING. 00200232
STUB AXLE. L/H 23224050
R/H 23225050
STUB AXLE NUT. 23225003 BEARING & FLANGE. 23226400
SEED TUBE
SEED TUBE & SKID. L/H 60068496
R/H 60068497 HD SEED TUBE & SKID. L/H 60068498
R/H 60068499 MOUNTING BOLT. 00360781 SLEEVE. 95194356
SPRING. 00170279
WASHER. 23224663
NUT. 00350635
TRAP ROLLER
HALF RIM LEFT. 24142601
HALF RIM RIGHT. 24142701 HALF RIM RIGHT WITH BEARING. 24142700 BEARING. 00240199
HALF RIM BOLTS. 00360758
HALF RIM NUTS. 00350067
HALF RIM WASHERS. 00370103
RIM AXLE BOLT. 23010204
DUST PLUG. 24142602
ARM. L/H 60051771
R/H 23226600 ARM PIVOT BUSH. 00200264
ARM PIVOT BOLT. 00370540
GUIDE PLATE. 23224111
INDEXING BOLT. 00371172
PRESS WHEEL
BEARING ASSEMBLY. 23042700
PRESS WHEEL - STEEL. 23224099
PRESS WHEEL - STAR. 23224088
PRESS WHEEL BOLT. 00360193
PRESS WHEEL ARM. 95194467
PIVOT SHAFT. 95194464
PIVOT BUSH x2. 95194023 PIVOT SHAFT O RING x2. 00265186
DOWN FORCE SPRING. L/H 23224210
R/H 23225210
DOWNFORCE BOLT. 00360057 DOWNFORCE WASHER. 23224205
ADJUSTING PLATE. L/H 23224060
R/H 23225060
PRESS WHEEL SHIM. 1mm 00230314
1.5mm 00230153
ANGLE BLOCK. L/H 23224208
R/H 23225208 ANGLE BLOCK BOLT. 00360193
ANGLE BLOCK SLEEVE. 24111501
